First Night Image of MAHLI Calibration Target in White Lighting

This image of a calibration target illuminated by white-light LEDs (light emitting diodes) is part of the first set of nighttime images taken by the Mars Hand Lens Imager (MAHLI) camera at the end of the robotic arm of NASA's Mars rover Curiosity. The set includes images of the MAHLI calibration target and of a Martian rock target called "Sayunei." MAHLI took the images on Jan. 22, 2013 (PST), after dark on the 165th Martian day, or sol, of the rover's work on Mars. For scale, the Lincoln penny on the MAHLI calibration target is three-fourths inch (19 millimeters) in diameter. The calibration target is mounted on the rover. This image was taken from a lens distance of 3.9 inches (10 centimeters). The illumination was MAHLI's four white-light LEDs. The reflection of one pair of LEDs is seen near the center of the image. The other pair is toward the center-left and is less visible because the surface there is less reflective. Malin Space Science Systems, San Diego, developed, built and operates MAHLI and the MAHLI engineering model. NASA's Jet Propulsion Laboratory, Pasadena, Calif., manages the Mars Science Laboratory Project and the mission's Curiosity rover for NASA's Science Mission Directorate in Washington. Curiosity and the mission's Vehicle System Test Bed rover were designed and built at JPL, a division of the California Institute of Technology in Pasadena. For more about NASA's Curiosity mission, visit: http://www.jpl.nasa.gov/msl , http://www.nasa.gov/mars , and http://mars.jpl.nasa.gov/msl .

Image credits: NASA/JPL-Caltech/MSSS
Image released by NASA on 2013-01-24 as catalog id PIA16713
